TPU / ABS Plastic Sheet Extrusion Line Making Machine 800kg/hr
Plastic sheet making machine
1.Mono-layer and multi-layer
2.Virgin and all recycled raw material
3.CE,ISO9001:2008and SGS certificate
4.With nearly for 15year’s experience
Description:
1.Screw apply special design of mixing and plasticizing function.
2.Coat hanger type die apply special double throttle design, much more accurate adjustment of width of production.±1℃ temperature control to make more accurate plasticizing process and sheet width control.
3.Three-roller calender apply level, vertical and 45℃ bevel type and can be lifted freely.
4.The sheet width is accurately controlled by adjusting the screw and rollers
Separate control system of roller temperature can make thickness equably extrusion
5.Slicing machine, accurate board length and quantity.
6.Winder with big torque motor, regulate its speed and tension force freely.
7.Equipped with metering machine to set the length of product.
Applications:
1.PP/PS single-layer, co-extrusion two-color, double-side transparent sheets are used in thermoforming and packing Industry.
2.PP transparent sheet, dull polish sheet (coarse and fine), two-color sheet and some other sheets are used in stationery industry.
3.PP foaming sheet is mainly used for folder of stationery industry and separation plate of packaging field, also is used for producing visor,acoustic panel, luggage rack, interior decoration parts,cover, and box etc. in car interior decoration industry.
4.PS electricity conductive sheet: Mainly used for packing of semi-conductive electric components, computer products which require no dust, not Static-electricity, no radio frequency or facilities.
Parameter:
Model | 150/120/90-180 | 150/60-1200 | 130/60-1000 | 1200-1000 | 100-800 |
Product width | 1500mm | 1000mm | 900mm | 800mm | 600mm |
Product thickness | 0.3-2mm | 0.3-2mm | 0.3-2mm | 0.2-2mm | 0.1-0.8mm |
Design capacity | 800-1000kg/hr | 800kg/hr | 550-600kg/hr | 350-400kg/hr | 200-250kg/hr |
Design line speed | 40M/min | 40M/min | 30M/min | 25M/min | 20M/min |
Calender diameter | Φ700mm | Φ700mm | Φ500mm | Φ500mm | Φ400mm |
Why choose us ?
1.We supply all the technical support,such as engineers,drawings,and instruction manual.
2.We send one or more than one engineers to client for installing and adjust all the machinery
3.Buyer also can sent workers to our workshop for learning how to conduct Plastic extruder
4.Supply formula guide service and staple raw material purchase.
5.We could supply the Feasibility Analysis Report for the project.
6.We could supply turnkey project to you.
